Technical Specifications

FOLD

All technical details at a glance.

FrameAluminium 7005 T6
ForkCrMo 4130 – Thru axle M15 x P1.5
Weight28 kg
Wheel size20″ / 20″
RimsAluminium double-wall, 32 holes
Spokes13G heavy duty
TiresSCHWALBE PICK-UP
Front hubShimano hub dynamo DH-UR708-3D
Rear hub135 mm – 32 holes
Front brakesShimano MT401 / MT420
Rear brakesShimano MT401 / MT410
Brake rotors180 mm
SteeringCable steering (2×2 system)
HandlebarSatori DEVIANT 3
Adjustable stemFOLD, adjustable (6 positions, 100 mm)
StemSatori VIPER
GripsErgon GP10
SeatpostSatori SORATA
SaddleVelo VL-4494
PedalsFoldable pedals
KickstandFOLD
Rear rackFOLD
Gear hubShimano Alfine 8 (optional: Alfine 11 or Rohloff)
DriveBelt drive
Ratio50T / 28T
LightsDynamo – Supernova E3 PURE 3 / TL3 MINI
